PhylrichJamestown Single Handle Faucet High Spout165-05-24B
9-15/16" H
Finishes and Colors: Burnished Gold
$1,166.40
Free Shipping
damage free guarantee
If you follow the simple guidelines below and find any damage on your product, we guarantee to promptly send you a free replacement.
damage free guarantee
If you follow the simple guidelines below and find any damage on your product, we guarantee to promptly send you a free replacement.
Phylrich 165-05-24B Specs
| Number of Faucet Holes | 2 |
|---|---|
| Spout Projection | 8-7/16" |
| Spout Style | Gooseneck Spout |
| Handle Style | Cross |
| Installation | Deck Mount |
| Height | 9-15/16" |
| Collection | Jamestown |
| Drain Assembly Included | Yes |
| Flow Rate | 1.2 GPM |
| Vessel Faucet | No |
| Handle Material | Metal |
| Handle Position | Side |
| Number of Handles | 1 |
| Distance from Aerator to Deck | 5-5/16" |
| Faucet Style | Single Lever |
| Overview |
|
|---|---|
| Brand | PhylrichShop All Phylrich |
| Collection | JamestownShop All Jamestown |
| Model Number | 165-05-24B |
| Alternative SKU | Phylrich 165-05-002, Phylrich 165-05-003, Phylrich 165-05-004, Phylrich 165-05-008, Phylrich 165-05-014, Phylrich 165-05-015, Phylrich 165-05-024, Phylrich 165-05-025, Phylrich 165-05-026, Phylrich 165-05-03Ushow more |
Details
- ADA Compliance: No
- Deck Thickness Maximum: 2"
- Deck Thickness Minimum: 1/8"
- Drain Assembly Material: Brass
- Drain Style: Push-to-Close
- Handle Fitting Hole Diameter: 1 1/8"
- Number of Holes: Two Hole
- Number of Handles: One
- Spout Height: 9 15/16"
- Spout Length: 6 9/16"
- Handle Spread Maximum: 12"
- Handle Spread Minimum: 8"
- Handle Turn Angle: Quarter Turn
- Inlet Connection Type: Male 1/2" NPSM
- Installation Type: Deck Mounted
- Primary Material: Brass
- Valve Material: Ceramic
- Flow Restriction: 1.2 gpm
- Water Pressure Maximum: 85 PSI
- Water Pressure Minimum: 20 PSI
- Water Pressure Recommended: 60 PSI
